Sacrificial anode series
Home > Products > Sacrificial anode series
Main use: for high resistivity environment, the protection of the pipe within the casing, the pipeline temporary cathodic protection, storage tank and pipe network protection, anti-electric interference grounding grid.
Execution standard：ASTM B 843-1995 SY/T0019-1997
Chemical composition
brand | Al | Zn | Mn | Fe | Ni | Cu | Si | Mg |
| Mg-Mn | <0.010 | - | 0.5-1.30 | <0.03 | <0.001 | <0.02 | - | allowanc |
| Mg | <0.010 | <0.010 | <0.030 | <0.002 | <0.001 | <0.001 | <0.010 | >99.95 |
specifications
The serial number | specifications | Core diameter （mm） | The weight of th （kg/m） | brand | ||
| A(mm) | B(mm) | C(mm) | ||||
| 1 | 19(3/4) | 9.5(3/8) | 305(1000) | 3.4(0.135) | 0.395(0.020) | Mg-Mn |
| 2 | 19(3/4) | 9.5(3/8) | 305(1000) | 3.4(0.135) | 0.357(0.020) | Mg |
